Eventide MixingLink Microphone Preamplifier with FX Loop w/Box (Used)

This unit in very good condition with no damage or visible wear. It has been tested and is working with no issues. The original box, paperwork and power supply are all included.

From Eventide

FEATURES:
-FX Loop Send and Return supports Balanced and Unbalanced signals - interfaces with consoles or guitar pedals easily

-Latching or Momentary Footswitch control of FX Loop for performance effects

-Works with a wide range of microphones including condenser and ribbon mics with up to 65dB of clean gain

-Aux I/O connection supporting stereo input and send

-Guitar Amp output and Headphone monitor output with separate master volume control

-International universal power supply included

-Operates on 9V battery
(No phantom power)

-48V Phantom power for Condenser mics

-Balanced XLR Output which supports DI and Line levels

-Instrument and Balanced Line level inputs

-Versatile Mix Control supports 3 modes- 100% Mic w/FX blended in, or Mic/FX balance control, or 100% FX (no Mic)

SPECIFICATIONS

Analog Input - MAX Input Levels, Input Impedance
INST IN: +10dBu, 500kΩ
XLR LINE IN: +24dBu, 22kΩ
XLR MIC IN: +4dBu, 2kΩ
FROM FX: +10dB, 200kΩ
AUX IN: +4dBu, 5.0kΩ

Analog Output - MAX Output Levels, Output Impedance
TO FX: +10dBu, 400Ω
TO AMP: +10dBu, 250Ω
PHONES: 150mW per channel, min Load = 8 Ohms
DI/LINE OUT: (DI) -10dBu, (LINE) +18dBu, 200Ω
AUX OUT: 18mV, 200Ω (mobile mic level)
