NUX B-6 Pro Wireless System For Wind Instruments

Microphone Type: Condenser

Polar Patterns: Cardioid

Microphone Sensitivity: -51dB

TX (Transmitter) / RX (Receiver)

Operating Frequency Band: 2400-2483.5MHz

RF Output Power: Maximum 10mW E.I.R.P

Transmission Distance: Up to 165 feet line-of-sight

Latency: 3.6ms (Low Latency), 6.1ms (Default), 9.9ms (Stable)

Sampling Depth / Sampling Rate: 24bit/48kHz

Frequency Response Range: 20Hz-20kHz

Maximum Audio Signal Output: 6.4dBV (SEND/OUTPUT)

THD+N: <0.01% (Typical)

Dynamic Range: 112dBA (SEND/OUTPUT)

Battery Capacity: TX (transmitter) 3.7V/500mAh, RX (receiver) 3.7V/3000mAh

Battery Life: TX (transmitter) up to 7 hours, RX (receiver) up to 11 hours

Power: DC9V, 1A (minimum), negative tip power supplies (Receiver)

Auto Power Off: Automatic power off after 10 minutes of no wireless connection

TX (Transmitter) Dimensions (excluding microphone): 61(L)x60(W)x30(H)mm

TX (Transmitter) Weight (excluding microphone): Approximately 60g

RX (Receiver) Dimension: 93(L)x120(W)x60(H)mm

RX (Receiver) Weight: 420g
