NUX B8 2.4GHz Wireless System For Guitar & Bass

Operating Frequency Band 2400-2483.5MHz

Audio Quality 24bit/48kHz

Frequency Response 20Hz-20kHz

Latency 2.5ms(best performance setting)-8.7ms(safety mode)

Input Impedance 1 MO

Maximum Input Level 1 kHz at 1% THD +6.2 dBV (5.78 Vp-p)

THD+N 0.01% 1kHz, typical

Dynamic Range 122dB, A-weighted(OUTPUT/SEND)

Output level Adjustment Range mute -64dB~0dB

Auto-sleep Mode N/A

Built-in Battery Capacity 3.7V/500mAh Rechargeable Li-polymer (Transmitter)

TX Battery Life up to 6.5 hours

Power Requirements 7V to 12V DC, 500mA min, negative tip power supplies(Receiver)

Operation Range Up to 50 m (165 feet) maximum

TX dimesions 72.5mm*49.3mm*23mm (L*W*H)

TX weight 63g

RX dimensions 122*95*60mm (L*W*H)

RX weight 500g
